In-depth: Building a memory system – Fundamentals

Author: by Stefan Reinalter

[In this reprinted #altdevblogaday in-depth piece, FH Technikum Wien lecturer and former Sproing Interactive senior programmer Stefan Reinalter begins his series on building your own memory system for a game or engine.] Today, I want to start a series on how to build your own memory system to be used in your game or engine. The series will cover how to handle allocations with vastly different lifetimes using specialized allocators, how to handle alignment restrictions, how to implement debugging features like memory tracking and tagging, and more. Before we can start, we need to delve into the inner workings of new, new[] delete and delete[] today – you may be surprised about some of the subleties involved. In order to keep things simpler and only concentrate on the crucial elements, we don't deal with per-class new/delete, and we don't want to mess with exceptions either, as they are rarely used in run-time game code. new operator / operator new The first thing to understand is that there is a difference between the new operator and operator new. Let's look at a very simple statement involving the keyword new:

T* object = new T;

This is the simplest form of the new operator, probably used in many, many places in your code. What does it really do behind the scenes?

If T is of fundamental type (e.g. int, float, etc.), or does not have a constructor, no constructor will be called. The above statement will call the simplest form of operator new:

void* operator new(size_t bytes);

Notice the size_t argument – the compiler will automatically insert code for calling operator new with the correct size for a given type, which is sizeof(T) in our case. Because operators behave like ordinary functions, they can be called manually, and can have different overloads as well. Those overloads can also be invoked by using different versions of the new operator, with the compiler generating code for calling the corresponding version of operator new. In fact, there's another standard version of the new operator, with so called placement-syntax:

void* memoryAddress = (void*)0x100;
T* object = new (memoryAddress) T; // placement-syntax, known as placement new

This can be used to construct instances of classes at a certain place in memory, which in essence is the only way of calling constructors "directly", because no memory allocation is involved here – the above calls a different overload of operator new, which is the following:

void* operator new(size_t bytes, void* ptr);

Even though this form of operator new takes size_t as the first argument, it does not allocate any memory, and just returns the pointer given in the second argument. That's why our example simply invokes the constructor T::T() at address 0×100. The placement-syntax of the new operator is very powerful, because it allows us to invoke different overloads of operator new with an unlimited number of custom arguments. The only rule is that the first argument to every operator new must always be of type size_t, which will automatically be passed to it by the compiler. Again, let's look at an example illustrating the above:

void* operator new(size_t bytes, const char* file, int line)
{
  // allocate bytes
}

// calls operator new(sizeof(T), __FILE__, __LINE__) to allocate memory
T* object = new (__FILE__, __LINE__) T;

Leaving differences between global operator new and class operator new out of the equation, every use of the placement form of the new operator boils down to the following internally:

// calls operator new(sizeof(T), a, b, c, d) to allocate memory
T* object = new (a, b, c, d) T;

Which is semantically equivalent to:

T* object = new (operator new(sizeof(T), a, b, c, d)) T;

The magic of calling operator new is simply done by the compiler. Furthermore, remember that every overload of operator new can be called directly like ordinary functions, and we can do whatever we want with the different overloads. For example, we can even use templates if we want to:

template <class ALLOCATOR>
void* operator new(size_t bytes, ALLOCATOR& allocator, const char* file, int line)
{
  return allocator.Allocate(bytes);
}

This comes in handy later when we're about to use different allocators, and want to provide additional arguments like e.g. alignment boundaries. The placement-syntax allows us to conveniently allocate memory with e.g. the following single-line statement:

T* object = new (allocator, alignment, __FILE__, __LINE__) T;

delete operator / operator delete This is probably no big surprise, but again, it is crucial to understand that there is a difference between the delete operator and operator delete. Calling the delete operator on a previously new'ed instance will first call the destructor, and then operator delete. Apart from the reverse order of operations, there's another difference between new and delete: Regardless of which form of new we used to create the instance, the same version of operator delete will always be called (which is rather unfortunate when trying to implement advanced memory system techniques in later parts of the series):

// calls operator new(sizeof(T), a, b, c, d)
// calls T::T()
T* object = new (a, b, c, d) T;

// calls T::~T()
// calls operator delete(void*)
delete object;

The only time the corresponding operator delete is called by the compiler is when an exception is thrown inside operator new, so the memory can correctly be freed before the exception is propagated to the calling site. This is also the reason why every overload of operator new must always have a corresponding version of operator delete, even if it's never called. But let's not digress, we don't want to deal with exceptions further. Like operator new, operator delete can also be called directly (like an ordinary function):

template <class ALLOCATOR>
void operator delete(void* ptr, ALLOCATOR& allocator, const char* file, int line)
{
  allocator.Free(ptr);
}

// call operator delete directly
operator delete(object, allocator, __FILE__, __LINE__);

However, do not forget that the destructor is called by the delete operator, not operator delete. Hence, in the above example, the destructor needs to be called manually:

// call the destructor
object->~T();

// call operator delete directly
operator delete(object, allocator, __FILE__, __LINE__);

If instances are created wih the simple placement-form of new, the destructor must always be called manually. Using delete on such an instance would invoke undefined behaviour (because the memory was never allocated with a call to new). Keep this in mind whenever you use placement new! Having thoroughly discussed new/delete, let us take a look at their array siblings, new[] and delete[]. new[] / delete[] Even though you have probably used it a thousand times already, you may not realize that in something so fundamental such as
